| MODEL | 5FA-600 | 5FA-800 | |||||
|---|---|---|---|---|---|---|---|
| CONTORLLER |
MITSUBISHI、SIEMENS |
||||||
| TYPE | SP16 | SP24 | SP16 | SP24 | |||
| X、Y AXIS TRAVEL | 600 x 400mm | 800 x 550mm | |||||
| Z AXIS TRAVEL | 400mm | 550mm | |||||
| B AXIS TRAVEL | ± 110° | ± 110° | |||||
| C AXIS TRAVEL | ± 360° | ± 360° | |||||
| SPINDLE SPEED | 16,000RPM | 24,000RPM | 16,000RPM | 24,000RPM | |||
| SPINDLE TAPER | BT40 | HSK-A63 | BT40 | HSK-A63 | |||
| SPINDLE MOTOR | 18KW/ 24HP | 18KW/ 24HP | 18KW/ 24HP | 18KW/ 24HP | |||
| ATC NO. | 16(24) |
16(24) |
|||||
